TowerRAID TR8UM6G - 8 Bay SATA to eSATA and USB 3.0 JBOD Enclosure (Black)

TowerRAID TR8UM6G - 8 Bay SATA to eSATA and USB 3.0 JBOD Enclosure (Black)
TowerRAID TR8UM6G - 8 Bay SATA to eSATA and USB 3.0 JBOD Enclosure (Black)

The TowerRAID TR8UM6G is an 8-bay storage enclosure for high capacity storage needs. With a built-in ventilating protective screen front panel, both units utilize a cable-less backplane-design to support up to eight hard drives. Unlike any other products in the market, TR8UM6G dual interface design allow both USB 3.0 and eSATA port multiplier connections for different connections. Connecting to the USB 3.0 slot for 5Gb/s performance, 8 hard drives can be accessed at the same time using a single USB 3.0 cable. Backwards compatible with USB 2.0, the TR8UM6G provides expandable storage with ease. 2 ports eSATA port multiplier connection allow maximum performance for the storage. Total 2 connections, each eSATA connection connect to 4 drives, allow dual channel performance for performance hungry applications. Hard drives are installed on easy access hard drive trays for simple insertion and removal. With support of the latest 8TB hard drives, the TR8UM6G is capable of having a total of 64TB in a single tower. Hard drive cooling is provided by a large 4.7” cooling fan located on the back of the unit. Supported in PC, MAC and Linux, the TR8UM6G is an ideal solution for your storage needs.

Note: Sans Digital recommends the use of enterprise hard drives when in use with any RAID controller applications. Standard desktop or green desktop drive may not be supported and may compromise RAID system stability and performance. For more information on the difference between RAID and desktop hard drives, please see the Western Digital knowledge base. For a list of compatible RAID Edition SATA hard drives, please CLICK HERE.
  • 2 x eSATA port multiplier and USB 3.0 connection
  • Backward compatible with USB 2.0
  • Access 8 hard drives using single USB 3.0 cables or 2x eSATA port multiplier.
  • 8 * Removable Hard drive trays for easy installation.
  • Compact and stylish 8-bay tower design with protective ventilating cover.

     Model  TR8UM6G
     Form Factor  Compact Tower
     HDD Trays  8 Removable 3.5" SATA
     RAID Level  JBOD
     Maximum Capacity  64TB (8TB Per hard drives)
     Host Interface & Transfer Rate  USB 3.0 x1, backwards compatible to USB 2.0
     eSATA Port Multiplier x 2
     Drive Interface  8 x 3.5” SATA (2.5" supported)
     Cooling Fan  4.7" Ball Bearing Fan
     Power Supply  250W (90V-264V)
     Control Interface  N/A
     Status Indicators  Power LED
     Dimension (in)  5.9"quot;W x 13.4"H x 13.4"D
     Weight (lb)  13
     Safety Regulations  CE, FCC, UL, RoHS
     Limited Warranty  1 Years
     Package Contents

     TR8UM6G (1)
     Hard Drive Trays (8)
     Power Cord (1)
     USB 3.0 Cable (1)
     eSATA Cables (2)
     Screws (1 set)
     Quick Installation Manual (1)

    Enterprise RAID Edition Hard Drive
     Model                    TR8UM6G  TR8UM6G8E  TR8UM6G16E
     Hard Drive  No HDD
     1TB RAID
     SATA x8
     2TB RAID
     SATA x8
     Storage Size
     N/A  8TB  16TB

     Model                    TR8UM6G32E  TR8UM6G48E  TR8UM6G64E
     Hard Drive  4TB RAID
     SATA x8
     6TB RAID
     SATA x8
     8TB RAID
     SATA x8
     Storage Size
     32TB  48TB  64TB
